Features:
1.Micro-Miniature, Innovative design
2.It has good feeling and long life
3.Snap-in type, can be mounted directly on P.C.Board and good for electrostatic discharge
4.It has a lot of choices for button shape and height and it is easily to install

Applications:
Include low power on/off designs, instrumentation, telecommunications, performance audio, computers/servers, networking and more.
1) Computer products
2) Consumer products
3) Communication equipments
4) Instrumentation

Welding Conditions:
1.Hand soldering
Use a soldering iron of 30 watts, controlled at 350oC approximately 3 seconds while solder applying
2.Wave soldering/Reflow Soldering
The peak temperature of the wave oven should be set to 260oC max. Condition for soldering Temperature Profile

Material:
1.Keystoke: Nylon/PBT  Black
2.Base: Nylon/PBT  Black
3.Contact: Copper-silver composite
4.Shell: IRON  Tin-plated

5.Terminal: Brass Plating silver
